indication
|
LCD / LED
|
Voltage range
|
1 – 1000 V AC (TRUE RMS)
1 – 1200 V DC
|
continuity test
|
yes / buzzer + yellow LED
|
phase-sequence test
|
yes / green LED
(left / right)
|
single-pole / phase test
|
yes / red ⚡ LED
|
polarity test
|
yes / LCD
|
load connection
via push buttons
|
Is = 550 mA
(1000 VDC)
|
30 mA FI triggering
via push button
|
yes
|
vibrating alarm
|
yes
|
measuring point illumination
|
yes
|
resistance measuring
|
0.1 kΩ – 300 kΩ
|
diode test
|
0.3 V – 2 V
|
frequency measuring
|
1 Hz – 1000 Hz
|
non-contact phase tester cable / break detector
|
yes / yellow LED (flashing)
|
protection class
|
IP 65
|
overload class
|
CAT IV 600 V
CAT III 1000 V
|
VDE / GS approval
|
yes
|
